Kyocera ECOSYS MA2100cfx User Manual

2-19
Installing and Setting up the Machine > Network Setup
6 Set the subnet mask.
7 Select the [OK] key.
8 [▲] [] key > [Default Gateway] > [OK] key
9 Set the default gateway.
10Select the [OK] key.
11[▲] [] key > [Auto-IP] > [OK] key
12[Off] > [OK] key
NOTE
You can set any value between 000 and 255.
Use the numeric keys or select the [▲] or [▼] key to enter a number.
Select the [◄] or [►] key to move the position being entered, which is shown highlighted.
NOTE
You can set any value between 000 and 255.
Use the numeric keys or select the [▲] or [▼] key to enter a number.
Select the [◄] or [►] key to move the position being entered, which is shown highlighted.
IMPORTANT
After changing the setting, restart the network from System Menu, or turn the
machine OFF and then ON.
Restart Network
(page 8-15)
NOTE
Ask your network administrator for the IP address in advance, and have it ready when you
configure this setting.
In the following cases, set the IP address of DNS server on the Command Center RX.
• When using the host name with "DHCP" setting set to "Off"
• When using the DNS server with IP address that is not assigned by DHCP automatically.
Setting the IP Address of the DNS Server, refer to the following:
Command Center RX User Guide

Kyocera ECOSYS MA2100cfx Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Automatic Document Feeder (ADF)	Yes (50 sheets)
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	417 x 429 x 495 mm
Duplex Printing	Automatic
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Functions	Print, Copy, Scan
Weight	26 kg
Print Speed (Black)	Up to 21 ppm (A4)
Print Speed (Color)	Up to 21 ppm (A4)
Copy Speed	Up to 21 cpm (A4 Black/Color)
