2-4

Installing and Setting up the Machine > Part Names (Connectors/Interior)

Part Names (Connectors/Interior)

1 TEL Connector

2 LINE Connector

3 USB Interface Connector

4 Network Interface Connector

5 Feed Cover

6 Paper Length Guide

7 Paper Width Guides

8 Multipurpose Tray

9 Tray Extension

10 Paper Width Guides

11 Fuser Cover

1 2

8 9
