Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)

Part Names (With Optional Equipments

Attached)

1 Cassette 2

2 Cassette 3

3 Cassette 4

4 Card reader

5 Rear cover 2

6 Rear cover 3

7 Rear cover 4

For details of options, refer to the following:

➡ Option configuration (page 737)
