Kyocera ECOSYS P2035d Service Manual

2PG/2PH
1-4-6
2610 PF paper feed motor error (Paper
feeder 1)
The PF paper feed motor of paper
feeder 1 ready input is not given for 2
s during the PF paper feed motor is
ON.
Defective harness
between PF paper
feed motor and PF
main PWB (YC4), or
improper connector
insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective drive
transmission system of
the PF paper feed
motor.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective PF main
motor.
Replace the PF main motor (Refer to the
service manual for the paper feeder).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
2620 PF paper feed motor error (Paper
feeder 2)
The PF paper feed motor of paper
feeder 2 ready input is not given for 2
s during the PF paper feed motor is
ON.
Defective harness
between PF paper
feed motor and PF
main PWB (YC4), or
improper connector
insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective drive
transmission system of
the PF paper feed
motor.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective PF main
motor.
Replace the PF main motor (Refer to the
service manual for the paper feeder).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
4000 Polygon motor (laser scanner unit)
error
The polygon motor ready input is not
given for 6 s during the polygon
motor is ON.
Defective harness
between polygon
motor and control
PWB (YC319), or
improper connector
insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective laser scan-
ner unit.
Replace the laser scanner unit (See page 1-
5-30).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P2035d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.7 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
