Kyocera ECOSYS P2035d Service Manual

2PG/2PH
1-4-7
6000 Broken fuser heater lamp wire
The fuser temperature does not rise
after the fuser heater lamp has been
turned on.
Poor contact in the
fuser thermistor con-
nector terminals.
Reinsert the connector (See page 1-5-16).
Poor contact in the
fuser heater lamp con-
nector terminals.
Reinsert the connector (See page 1-5-16).
Fuser thermistor
installed incorrectly.
Replace the fuser unit (See page 1-5-16).
Fuser thermal cutout
triggered.
Replace the fuser unit (See page 1-5-16).
Fuser heater lamp
installed incorrectly.
Replace the fuser unit (See page 1-5-16).
Broken fuser heater
lamp wire.
Replace the fuser unit (See page 1-5-16).
6020 Abnormally high fuser thermistor
temperature
Fuser thermistor detects abnormally
temperature.
When the temperature of a fuser
thermistor detects 195 °C or more at
the time of heater OFF and 155 °C or
more.
Shorted fuser thermis-
tor.
Replace the fuser unit (See page 1-5-16).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
6030 Broken fuser thermistor wire
Input from fuser thermistor is 0 (A/D
value).
Poor contact in the
fuser thermistor con-
nector terminals.
Reinsert the connector (See page 1-5-16).
Broken fuser thermis-
tor wire.
Replace the fuser unit (See page 1-5-16).
Fuser thermistor
installed incorrectly.
Replace the fuser unit (See page 1-5-16).
Fuser thermal cutout
triggered.
Replace the fuser unit (See page 1-5-12).
Fuser heater lamp
installed incorrectly.
Replace the fuser unit (See page 1-5-16).
Broken fuser heater
lamp wire.
Replace the fuser unit (See page 1-5-16).
6400 Zero cross signal error
The zero cross signal does not reach
the control PWB for specified time.
Defective harness
between high voltage
PWB (YC202) and
control PWB (YC311),
or improper connector
insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (See page 1-
5-19).
Defective harness
between power source
PWB (YC103) and
high voltage PWB
(YC201), or improper
connector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (See page 1-
5-22).
Defective power
source PWB.
Replace the power source PWB (See page
1-5-22).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P2035d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.7 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR
