Kyocera ECOSYS P3260dn User Manual

4-12
Printing from PC > Printing Data Saved on the Printer
Printing Data Saved on the Printer
If you configure settings in the [Job] tab of the printer driver and then print, the print job will be saved in the Job Box
(memory) and printing can be executed at the machine.
Follow the work flow below when using Job Box.
Specifying the Job Box from a comp
uter and sending the print job. (page 4-12)
Using the operation panel to specify
a file within a Box and printing it.
You can print the documents from the following boxes.
Printing Documents from Private Print Box (page 4-13)
Printing Document from Stored Job Box (page 4-15)
Printing Document from Quick Copy Box (page 4-17)
Printing Document from Proof and Hold Box (page 4-19)
Specifying the Job Box from a Computer and Storing
the Job
Use the procedure below to store data in a Job Box.
1 Click
[File] and select [Print] in the application. The Print dialog box displays.
2 Se
lect the machine from the "Name" menu.
3 Click
the [Properties] button. The Properties dialog box displays.
4 Click
the [Job] tab and select the [Job storage (e-MPS)] check box to set the function.
NOTE
• To use Stored Job Box and Quick Copy Box, an optional SSD must be installed in the
machine.
• For information on how to use the printer driver software, refer to the following:
Printer Driver User Guide

Kyocera ECOSYS P3260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	60 ppm
Duplex print speed (black, normal quality, A4/US Letter)	43 ppm
Display	LCD
Control type	Buttons
Certification	TUV-GS, CE
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	15000 - 25000 pages per month
Replacement cartridges	TK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking)
Number of print cartridges	1
Page description languages	Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, TIFF, XPS
Average cartridge yield (black)	40000 pages
Paper input type	Paper tray
Total input capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Maximum media length	915 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Banner
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Security algorithms	HTTPS, IPPS, IPSEC, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Optional connectivity	Ethernet, Parallel, Wireless LAN
Memory type	DDR3
Processor cores	2
Processor family	ARM Cortex
Compatible memory cards	SD, SDHC
Maximum internal memory	2500 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	50.4 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	1242 W
Power consumption (off)	0.07 W
Power consumption (ready)	11 W
Power consumption (printing)	721 W
Power consumption (PowerSave)	0.7 W
Energy Star Typical Electricity Consumption (TEC)	2.99 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Cables included	AC
Included cartridge capacity (black)	11000 pages
Package depth	517 mm
Package width	549 mm
Package height	455 mm
Package weight	20000 g
Sustainability certificates	Blue Angel, CE, REACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	416 mm
Width	410 mm
Height	363 mm
