Kyocera ECOSYS P3260dn User Manual

8-27
Setup and Registration (System Menu) > System Menu
Optional Network
Configure settings for the optional Network Interface Kit or Wireless Network Interface Kit.
Wireless Network
[Menu] key > [▲] [▼] key > [Optional Network] > [OK] key > [▲] [▼] key > [Wireless Network] > [OK] key
NOTE
This menu is displayed when the optional Network Interface Kit or Wireless Network Interface Kit is installed.
NOTE
This function is displayed when the optional Wireless Network Interface Kit is installed.
Item Description
ConnectionStatus When the optional Wireless Network Interface Kit is installed, you can check the wireless LAN status.
Quick Setup If the machine will connect to an access point that supports the automatic wireless network setup,
connection settings can be configured by Quick Setup.
AvailableNetwork Displays access points to which the machine can connect.
Push Button If the access point supports the push button method, wireless settings can be configured using
the push button. This setting executes push button, and the connection is started by pressing
the push button on the access point.
NOTE
The push button method supports only the WPS.
PIN (Device) Starts connection using the machine's PIN code. Enter the PIN code into the access point. The
PIN code of the machine is automatically generated.
PIN (Terminal) Starts connection using the PIN code of the access point. Enter the PIN code of the access point.
Custom Setup The detailed settings for wireless LAN can be changed. You can check the connection with a
wireless network by selecting [Connect].
Netwk Name(SSID) Set the SSID (Service Set Identifier) of the wireless LAN to which the machine connects.
NOTE
Up to 32 characters can be entered.
Connection Mode Set the connection mode.
Value: Ad
Hoc, Infrastructure
NOTE
Ad Hoc: Directly communicates with the device without going through an access point. This
method cannot be used to connect to two or more devices.
Infrastructure: Performs communication through an access point.
Channel Set channel. Use [▲] or [▼] or the numeric keys to enter a number.
Value: 1 to 11
Netwk Authentic. Select network authentication type. To select other options, open the device home page from a
computer.
Value: Open, Shared, WPA-PSK
*1
, WPA2-PSK
*1

Kyocera ECOSYS P3260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	60 ppm
Duplex print speed (black, normal quality, A4/US Letter)	43 ppm
Display	LCD
Control type	Buttons
Certification	TUV-GS, CE
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	15000 - 25000 pages per month
Replacement cartridges	TK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking)
Number of print cartridges	1
Page description languages	Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, TIFF, XPS
Average cartridge yield (black)	40000 pages
Paper input type	Paper tray
Total input capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Maximum media length	915 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Banner
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Security algorithms	HTTPS, IPPS, IPSEC, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Optional connectivity	Ethernet, Parallel, Wireless LAN
Memory type	DDR3
Processor cores	2
Processor family	ARM Cortex
Compatible memory cards	SD, SDHC
Maximum internal memory	2500 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	50.4 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	1242 W
Power consumption (off)	0.07 W
Power consumption (ready)	11 W
Power consumption (printing)	721 W
Power consumption (PowerSave)	0.7 W
Energy Star Typical Electricity Consumption (TEC)	2.99 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Cables included	AC
Included cartridge capacity (black)	11000 pages
Package depth	517 mm
Package width	549 mm
Package height	455 mm
Package weight	20000 g
Sustainability certificates	Blue Angel, CE, REACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	416 mm
Width	410 mm
Height	363 mm
