Kyocera ECOSYS P3260dn User Manual

8-3
Setup and Registration (System Menu) > System Menu
Menu Settings
This section explains the functions that can be configured in Menu. To configure the settings, select the item in System
Menu and select the setting item. For details on each function, see the table below.
Item Description Reference Page
Report Print Configure settings for printing reports and histories. page 8-4
Job Log History page 8-5
Counter This counts the number of pages printed. page 2-37
Paper Settings Configure settings for paper. page 8-6
Print Settings Configure settings for printing. page 8-10
Network Configures network settings. page 8-13
Primary Network Specify the network to be used for the send function, the network
authentication and connecting to external address book.
page 8-13
Optional Network Configure settings for the optional Network Interface Kit or Wireless
Network Interface Kit.
page 8-27
Language Select the language displayed on the message display. page 8-30
Def. Screen(Box) Select the screen to be displayed when [Document Box] key is selected. page 8-30
Date Setting Configure settings related to the date and time. page 8-30
Buzzer Set options for buzzer sound during the machine operations. page 8-31
RAM Disk Setting A RAM disk can be created and its size can be set. page 8-31
Format SSD Format an optional SSD. page 8-31
Format SD Card Format an optional SD/SDHC memory card. page 8-32
Display Bright. Set the brightness of the message display. page 8-32
Disp. Backlight Set the backlight of the message display. page 8-32
Error Handling Select whether to cancel or continue the job when error has occurred. page 8-32
Timer Setting Configure settings related to the time. page 8-33
Disp. Status/Log Set the display method of the Status/Log. page 8-34
KeyboardType Select the type of keyboard that you want to use. page 8-35
Bluetooth Set. Set the Bluetooth keyboard. page 8-35
Low Toner Alert Set the amount of remaining toner to notify the administrator when to
order a toner when the tone
r is running low.
page 8-35
Security The security functions can be set up to protect printer operation and the print data. page 8-36
I/F Block Set. This allows you to protect this machine by blocking the interface with
external devices such as USB host
s or optional interfaces.
page 8-36
Security Level The Security Level setting is primarily a menu option used by service personnel
for maintenance work. There is no need for customers to use this menu.
—
Data Security Configure settings for data stored in the optional SSD and machine's memory. page 8-37
User/Job Account Configures settings related to machine management.
User Login:
Overview of User Login Administration (page 9-2)
Job Accounting:
Overview of Job Accounting (page 9-14)
—

Kyocera ECOSYS P3260dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.5 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	60 ppm
Duplex print speed (black, normal quality, A4/US Letter)	43 ppm
Display	LCD
Control type	Buttons
Certification	TUV-GS, CE
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	15000 - 25000 pages per month
Replacement cartridges	TK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking)
Number of print cartridges	1
Page description languages	Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, TIFF, XPS
Average cartridge yield (black)	40000 pages
Paper input type	Paper tray
Total input capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Maximum media length	915 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Banner
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Security algorithms	HTTPS, IPPS, IPSEC, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Optional connectivity	Ethernet, Parallel, Wireless LAN
Memory type	DDR3
Processor cores	2
Processor family	ARM Cortex
Compatible memory cards	SD, SDHC
Maximum internal memory	2500 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	50.4 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	1242 W
Power consumption (off)	0.07 W
Power consumption (ready)	11 W
Power consumption (printing)	721 W
Power consumption (PowerSave)	0.7 W
Energy Star Typical Electricity Consumption (TEC)	2.99 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Cables included	AC
Included cartridge capacity (black)	11000 pages
Package depth	517 mm
Package width	549 mm
Package height	455 mm
Package weight	20000 g
Sustainability certificates	Blue Angel, CE, REACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	416 mm
Width	410 mm
Height	363 mm
