4-21
Printing from PC > Job Box Setting
Job Box Setting
Configures settings for Job Box.
1
Display the screen.
[Document Box] key > [▲] [] key > [Job Box Setting] > [OK] key
2
Configure the settings.
The available settings are shown below.
NOTE
If the default screen of the box is set to a Custom Box, display the Job Box screen.
[Document Box] key > [Back] key > [] [] key > [Job Box] > [OK] key
Item Description
Quick Copy Jobs To maintain free space on the box, you can set the maximum number of
stored jobs.
Value: number between 0 and 300
NOTE
When 0 is set, Quick Copy cannot be used.
JobRet. Deletion This setting specifies that documents, such as Private Printing, Quick
Copying, or Proof and Hold Printing, saved temporarily in the job box are
automatically deleted after they have been saved for a set time.
Value: Off, 1 hour, 4 hours, 1 day, 1 week
NOTE
This function is valid for documents saved after the function is set.
Regardless of this function setting, temporary documents are deleted
when the main power switch is turned off.
Storage Media Select which storage media to use.
Value: SSD, SD Card
NOTE
This setting is not displayed if the optional SSD or SD card is not
installed.

Table of Contents

Other manuals for Kyocera ECOSYS P3260dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS P3260dn and is the answer not in the manual?

Kyocera ECOSYS P3260dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)4.5 s
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)60 ppm
Duplex print speed (black, normal quality, A4/US Letter)43 ppm
DisplayLCD
Control typeButtons
CertificationTUV-GS, CE
Product colorBlack, White
Market positioningBusiness
Display number of lines5 lines
Printing colorsBlack
Maximum duty cycle300000 pages per month
Recommended duty cycle15000 - 25000 pages per month
Replacement cartridgesTK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking)
Number of print cartridges1
Page description languagesEpson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, TIFF, XPS
Average cartridge yield (black)40000 pages
Paper input typePaper tray
Total input capacity500 sheets
Maximum input capacity2600 sheets
Maximum number of input trays5
Multi-Purpose tray input capacity100 sheets
Custom media width105 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Maximum media length915 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLegal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Multi-purpose tray media typesBanner
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Cabling technology10/100/1000Base-T(X)
Security algorithmsHTTPS, IPPS, IPSEC, IPSec, SNMPv3
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Optional connectivityEthernet, Parallel, Wireless LAN
Memory typeDDR3
Processor cores2
Processor familyARM Cortex
Compatible memory cardsSD, SDHC
Maximum internal memory2500 MB
Sound pressure level (printing)56 dB
Sound pressure level (quiet mode)50.4 dB
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (max)1242 W
Power consumption (off)0.07 W
Power consumption (ready)11 W
Power consumption (printing)721 W
Power consumption (PowerSave)0.7 W
Energy Star Typical Electricity Consumption (TEC)2.99 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Cables includedAC
Included cartridge capacity (black)11000 pages
Package depth517 mm
Package width549 mm
Package height455 mm
Package weight20000 g
Sustainability certificatesBlue Angel, CE, REACH, RoHS, EPEAT Silver, ENERGY STAR
Operating altitude0 - 3500 m
Non-operating altitude0.6 - 15000 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)15 - 80 %
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth416 mm
Width410 mm
Height363 mm
