Kyocera ECOSYS P7035cdn User Manual

4-22 Using the Operation Panel
Detail (Shows the details of the selected file)
Use this to view detailed information on the files and folders in the USB
memory.
1 Use the procedure described in Print File (Printing and checking the
files in the USB memory) on page 4-20 to display a list of the files or
folders you want to check.
2 Press  or  to select the folder or file you want to check.
3 Press [Detail] ([Right Select]). The Detail screen appears.
If you selected a file, there are 4 Detail screens. Press  or  to
move between the screens.
If you selected a folder, there are 2 Detail screens. Press  or  to
move between the screens.
If the entire name shown as the File Name or Folder Name will not fit
on one line, pressing [Detail] ([Right Select]) changes to a 3-line
name display. If the name is 3 or more lines long, you can scroll up or
down by pressing  or .
Pressing [OK] while file or folder details are displayed returns you to the
USB Memory menu.
Remove Memory (Removing the USB memory)
Allows you to remove a USB memory device.
1 In the USB Memory menu, press  or  to select Remove Memory.
2 Press [OK]. The printer is now ready for the USB memory to be
removed and the Mode Selection menu screen appears.
IMPORTANT If the screen on the left appears, the USB memory is
still being used. Wait until the relevant job (e.g. printing from the USB
memory) has ended and then repeat the Remove Memory procedure.
Detail: P b
File Name: 1/ 4
ABCDEFGHIJKLMNOPQRST
N
[ Detail ]
Detail: P b
Folder Name: 1/ 2
ABCDEFGHIJKLMNOPQRST
N
[ Detail ]
Detail: P b
File Name: 1/ 4
ABCDEFGHIJKLMNOPQRST
N
[ Detail ]
Detail: O b
ABCDEFGHIJKLMNOPQRSTU
VWXYZabcdefghijklmnop
qrstuvwxyz1234567890
Cannot remove the
memory while in use.

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
