Using the Operation Panel 4-23
Custom Box
IMPORTANT To use a Custom Box, an optional SSD must be
installed in the printer. The SSD must be formatted from the printer.
For more information, refer to Format SSD on page 4-87.
A Custom Box is a general-purpose box that allows users to store print
data on the printer's SSD so that it can be reused as required.
Use the Command Center RX to create or delete a Custom Box, or to set
a Box Password. For more information, refer to the Command Center RX
Operation Guide and Printer Driver User Guide.
Use the printer's operation panel to print the print data stored in a Custom
Box.
The options available in Custom Box are as follows:
Box Password (input of the password)
Box number/Box name (Select a File)
Select/Deselect All Files
Print a File
Delete a File
Check Custom Box Details
Check File Details
1
Press [MENU].
2
Press or to select Custom Box. Box menu appears showing a
list of available actions.
3
Press or to select a Custom Box.
4
Press [OK]. The printer displays a list of files stored in the Custom
Box.
Box Password (input of the password)
The user who can access it can be limited by putting the password on the
Custom Box. The password is set from Command Center RX.
1
If you have set a password for the selected Custom Box, a password
input screen appears.
Press , , , or to select characters, and then press [OK] to
enter the password.
You can go back one character by pressing [Bckspace] ([Left
Select]).
Note
Please do the following procedure Box Password (input of
the password) when you set the password to the Custom Box.
Box List:
a
b
i
0001 ABC box
i
0002 XYZ box
i
0003 Common
m
0001 ABC box:
a
b
All Files
j
AAAA
T
j
BBBB
T
[ Menu ] [ Select ]
Box Password:
a
b

S
*
abcdefghijklmnopqrst
uvwxyzABCDEFGHIJKLMNO
[Bckspace] [ Enter ]

Table of Contents

Other manuals for Kyocera ECOSYS P7035cdn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS P7035cdn and is the answer not in the manual?

Kyocera ECOSYS P7035cdn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Duplex printing modeAuto
Time to first page (black, normal)8 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle150000 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input typeCassette, Paper tray
Total input capacity650 sheets
Total output capacity- sheets
Maximum input capacity2650 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity150 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length138 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesFolio (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Wi-FiNo
Mobile printing technologies-
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
Processor model465S
Processor familyPowerPC
Maximum internal memory1536 MB
Sound power level (standby)33.7 dB
Sound pressure level (printing)53.2 dB
DisplayLCD
CertificationTÜV/GS, CE
Product colorBlack, White
Display number of lines5 lines
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0 W
Power consumption (standby)86 W
Power consumption (printing)622 W
Power consumption (PowerSave)4 W
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificatesBlue Angel, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth518 mm
Width345 mm
Height512 mm
