FS-9120DN/9520DN
2-3-9
Terminals (YC) Voltage Remarks
21-5 21-2 0 - 5 V DC OPPWB FPDAT signal, input
21-6 21-2 5 V DC 5 V DC supply for OPPWB, output
22-A1 22-A2 5/0 V DC (pulse) Main controller PWB PRINTN signal, output
22-A3 22-A2 5/0 V DC (pulse) Main controller PWB SI signal, output
22-A4 22-A2 5/0 V DC (pulse) Main controller PWB SCLK signal, input
22-A5 22-A2 5/0 V DC (pulse) Main controller PWB SBSY signal, output
22-A6 22-A2 5/0 V DC (pulse) Main controller PWB SO signal, input
22-A7 22-A2 5/0 V DC (pulse) Main controller PWB RESET signal, output
22-A8 22-A2 5/0 V DC (pulse) Main controller PWB PDOUT signal, output
22-A10 22-A2 5/0 V DC (pulse) Main controller PWB VDATAP signal, input
22-A12 22-A2 5/0 V DC (pulse) Main controller PWB VDATAN signal, input
22-A14 22-A2 5/0 V DC (pulse) Main controller PWB FPCLK signal, output
22-A15 22-A2 5/0 V DC (pulse) Main controller PWB FPDAT signal, input
22-A17 22-A2 5/0 V DC (pulse) Main controller PWB VDATA signal, input
22-B1 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B2 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B3 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B4 22-A2 5/0 V DC (pulse) Main controller PWB SDIR signal, output
22-B5 22-A2 5/0 V DC (pulse) Main controller PWB ESGIR signal, output
22-B6 22-A2 5/0 V DC (pulse) Main controller PWB VDFON signal, output
22-B7 22-A2 5/0 V DC (pulse) Main controller PWB VSREQN signal, output
22-B12 22-A2 5/0 V DC (pulse) Main controller PWB FPDIR signal, output
22-B13 22-A2 5/0 V DC (pulse) Main controller PWB FPPOWER signal, output
22-B15 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B16 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B17 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B18 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B19 22-A2 5 V DC Main controller PWB 5 V DC supply, output
22-B20 22-A2 5 V DC Main controller PWB 5 V DC supply, output
To Next Page
