Service items Description
1-4-4
FS-9120DN/9520DN
Item Description
4 Software jumper switch information First byte
(Hexadecimal) Bit 0: always 0
Bit 1: 0: Overseas 1: Domestic (Japan)
Bit 2: Not used
Bit 3: Not used
Bit 4: 0: Kyocera 1: OEM
Bit 5: 0: For Europe 1: For U.S.
Bit 6: 0 Non MICR mode 1: MICR mode
Bit 7: Not used
Second byte
OEM information: Displayed in OEM mode only.
5 Total page counter
6 Toner install information
7 Parallel I/O information
8 Serial I/O error code 00: Normal
Bit 0: Framing error
Bit 1: Overrun error
Bit 2: Parity error
9 Operation panel key lock status 01: Partial lock
(Displayed only when locked) 02: Full lock
0 NVRAM error code 01: ID error
(Displays only when error occurred) 02: Version error
03: Checksum error
04: NVRAM crush error
! NVRAM downloading status 00: Normal downloaded
Bit 0: Font data
Bit 1: Host data
Bit 2: Macro data
Bit 3: Program data
Bit 4: Operator panel message data (File name displayed)
Bit 5: OEM data
Bit 6: Reserved
Bit 7: Error occurred
@ Printable area information Top offset / Left offset / Page length / Page width
# Left offset MP tray / Cassette 1 / Cassette 2 / Cassette 3 / Cassette 4 /
Duplex unit
$ Top offset MP tray / Cassette 2 / Cassette 3 / Cassette 4 / Duplex unit
% Life counter of MP tray MP tray (total) / MP tray (small) / MP tray (large)*
^ Life counter of paper feed position Cassette 1 (total) / Cassette 1 (small) / Cassette 1 (large)*
Cassette 2 (total) / Cassette 2 (small) / Cassette 2 (large)*
Cassette 3 (total) / Cassette 3 (small) / Cassette 3 (large)*
& Life counter of paper feed position Cassette 4 (total) / Cassette 1 (small) / Cassette 1 (large)*
* Life counter of duplex unit Duplex unit (total) / Duplex unit (small) / Duplex unit (large)*
( Life counter of each unit Drum / Developer / Fuser
) Life counter of document finisher (1)Total (for DF-70,73 and 75) / Main tray (for DF-70,73 and 75)
/ Sub tray (for DF-70) / Book-let tray page (for DF-75)
/ Book-let tray (for DF-75)
/ Staple total (for DF-70,73 and 75)
/ Staple (upper left) (for DF-70 and 75)
/ Staple (lower left) (for DF-70 and 75)
/ Staple (two positions) (for DF-70 and 75)
*"Small" means sizes A4/letter or smaller
*Total = large x 2 + small
