Kyocera FS-C2026MFP+ User Manual

2MA/2MB
2-3-15
YC12 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 GND - - Ground
5 GND - - Ground
YC14 A1 NC - - Not used
Connected to
KUIO slot
B1 NC - - Not used
A2 NC - - Not used
B2 NC - - Not used
A3 GND - - Ground
B3 3.3V O 3.3 V DC 3.3 V DC power output
A4 3.3V O 3.3 V DC 3.3 V DC power output
B4 A15 O 0/3.3 V DC (pulse) Address bus signal
A5 GND - - Ground
B5 A14 O 0/3.3 V DC (pulse) Address bus signal
A6 A13 O 0/3.3 V DC (pulse) Address bus signal
B6 A12 O 0/3.3 V DC (pulse) Address bus signal
A7 A11 O 0/3.3 V DC (pulse) Address bus signal
B7 A10 O 0/3.3 V DC (pulse) Address bus signal
A8 A9 O 0/3.3 V DC (pulse) Address bus signal
B8 A8 O 0/3.3 V DC (pulse) Address bus signal
A9 GND - - Ground
B9 A7 O 0/3.3 V DC (pulse) Address bus signal
A10 A6 O 0/3.3 V DC (pulse) Address bus signal
B10 A5 O 0/3.3 V DC (pulse) Address bus signal
A11 A4 O 0/3.3 V DC (pulse) Address bus signal
B11 A3 O 0/3.3 V DC (pulse) Address bus signal
A12 A2 O 0/3.3 V DC (pulse) Address bus signal
B12 A1 O 0/3.3 V DC (pulse) Address bus signal
A13 GND - - Ground
B13 3.3V O 3.3 V DC 3.3 V DC power output
A14 OP2IFN O 0/3.3 V DC Select signal
B14 OP2ACKN I 0/3.3 V DC (pulse) OP2ACKN signal
A15 OP2IRN I 0/3.3 V DC Interruption signal
B15 5V O 5 V DC 5 V DC power output
A16 RDY O 0/3.3 V DC Ready signal
Connector Pin Signal I/O Voltage Description

Kyocera FS-C2026MFP+ Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Media thickness	0.11 mm
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	514 x 550 x 580 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows, Mac 10.4+, UNIX LINUX
PCL fonts	93
Digital sender	No
Maximum duty cycle	65000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	25 ppm
Scan speed (color)	35 ppm
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	1300 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	1024 MB
Processor model	464
Processor family	PowerPC
Maximum internal memory	2048 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	16 W
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE
