Kyocera FS-C2026MFP+ User Manual

2MA/2MB
2-3-16
YC14 B16 RXDREQ I 0/3.3 V DC Reception DMA request signal
Connected to
KUIO slot
A17 GND - - Ground
B17 RXDMACKN O 0/3.3 V DC (pulse) Reception DMACK signal
A18 IORN O 0/3.3 V DC Read enable signal
B18 IOWN O 0/3.3 V DC Write enable signal
A19 RESETN O 0/3.3 V DC Reset signal
B19 VOLTDETECT - - Ground
A20 D15 I/O 0/3.3 V DC (pulse) Data bus signal
B20 D14 I/O 0/3.3 V DC (pulse) Data bus signal
A21 GND - - Ground
B21 D13 I/O 0/3.3 V DC (pulse) Data bus signal
A22 D12 I/O 0/3.3 V DC (pulse) Data bus signal
B22 D11 I/O 0/3.3 V DC (pulse) Data bus signal
A23 D10 I/O 0/3.3 V DC (pulse) Data bus signal
B23 D9 I/O 0/3.3 V DC (pulse) Data bus signal
A24 D8 I/O 0/3.3 V DC (pulse) Data bus signal
B24 D7 I/O 0/3.3 V DC (pulse) Data bus signal
A25 GND - - Ground
B25 D6 I/O 0/3.3 V DC (pulse) Data bus signal
A26 D5 I/O 0/3.3 V DC (pulse) Data bus signal
B26 D4 I/O 0/3.3 V DC (pulse) Data bus signal
A27 D3 I/O 0/3.3 V DC (pulse) Data bus signal
B27 D2 I/O 0/3.3 V DC (pulse) Data bus signal
A28 D1 I/O 0/3.3 V DC (pulse) Data bus signal
B28 D0 I/O 0/3.3 V DC (pulse) Data bus signal
A29 GND - - Ground
B29 NC - - Not used
A30 NC - - Not used
B30 NC - - Not used
YC15 1 OUT- O Analog Speaker sound signal (-)
Connected to
speaker
2 OUT+ O Analog Speaker sound signal (+)
Connector Pin Signal I/O Voltage Description
