2MA/2MB
2-3-17
YC32 1 FEEDCL O 0/24 V DC DPPFCL: On/Off
Connected to
DP drive
PWB
2 REVSOL O 0/24 V DC DPSBSOL: On/Off
3 PRESOLN O 0/24 V DC DPPRSOL: On (Press)/Off
4 RELSOLN O 0/24 V DC DPPRSOL: On (Release)/Off
5 DPDETN I 0/3.3 V DC DP set signal
6 OPSWN I 0/3.3 V DC DPOCS: On/Off
7 ORGSWN I 0/3.3 V DC DPOS: On/Off
8 TIMSWN I 0/3.3 V DC DPTS: On/Off
9 GND - - Ground
10 +3.3V2 O 3.3 V DC 3.3 V DC power to DPDPWB
11 GND - - Ground
12 +24V2 O 24 V DC 24 V DC power to PDPWB
13 MOTB2 O 0/24 V DC (pulse) DPPFM drive control signal
14 MOTA2 O 0/24 V DC (pulse) DPPFM drive control signal
15 MOTB1 O 0/24 V DC (pulse) DPPFM drive control signal
16 MOTA1 O 0/24 V DC (pulse) DPPFM drive control signal
YC36 1 SCMOTB2 O 0/24 V DC (pulse) ISUM drive control signal
Connected to
ISU motor
2 SCMOTA1 O 0/24 V DC (pulse) ISUM drive control signal
3 SCMOTB1 O 0/24 V DC (pulse) ISUM drive control signal
4 SCMOTA2 O 0/24 V DC (pulse) ISUM drive control signal
YC37 1 +24V1 I 24 V DC 24 V DC power from PSPWB
Connected to
power source
PWB
2 GND - - Ground
3 GND - - Ground
4 +5V1 I 5 V DC 5 V DC power from PSPWB
YC38 1 GND - - Ground
Connected to
laser scanner
unit KM
2 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-M
3 PDMN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
4 VDOMP O LVDS APCPWB-M video data signal (+)
5 VDOMN O LVDS APCPWB-M video data signal (-)
6 GND - - Ground
7 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-K
8 PDKN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
9 VDOKP O LVDS APCPWB-K video data signal (+)
10 VDOKN O LVDS APCPWB-K video data signal (-)
Connector Pin Signal I/O Voltage Description

Kyocera FS-C2026MFP+ Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Media thickness	0.11 mm
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	514 x 550 x 580 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows, Mac 10.4+, UNIX LINUX
PCL fonts	93
Digital sender	No
Maximum duty cycle	65000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	25 ppm
Scan speed (color)	35 ppm
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	1300 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	1024 MB
Processor model	464
Processor family	PowerPC
Maximum internal memory	2048 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	16 W
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE
