Kyocera FS FS-1020D User Manual

Paper Jam Removal
3-17
2
Pull the paper cassette all the way out of the printer.
Figure 3-4
3
Open the duplexer’s rear cover and remove any jammed paper.
Figure 3-5
4
Open the duplexer’s front cover and remove any jammed paper.
Figure 3-6
5
Insert the paper cassette into the slot in the printer.
6
Open and close the printer’s top cover to clear the error. The printer
then automatically warms up and resumes printing.
Paper Cassette
Duplexer’s Rear Cover
Duplexer’s Front Cover

Kyocera FS FS-1020D Specifications

General

Print Technology	Laser
Resolution	600 x 600 dpi
Memory	32 MB
Standard Input Capacity	250 sheets
Connectivity	USB 2.0
Print Speed	20 ppm
Paper Sizes	A4, A5, A6, B5, Letter, Legal
Operating System Compatibility	Windows, Mac, Linux
Warm-up Time	Less than 15 seconds
Time to First Page	Less than 10 seconds
