B-1
Appendix B
Host Computer
Interface
B
This appendix describes the signals used in the laser printer’s parallel, USB,
and serial (option) interfaces. It also lists pin assignments, signal functions,
timings, connector specifications, and voltage levels. For details on the
network interface, refer to the IB-21E/IB-22 User’s Manual contained on the
CD-ROM that is supplied with the printer.
This appendix explains the following topics:
• Parallel Interface
• USB Interface
• Serial Interface (Option)
• RS-232C Protocol

Kyocera FS FS-1020D Specifications

General

Print Technology	Laser
Resolution	600 x 600 dpi
Memory	32 MB
Standard Input Capacity	250 sheets
Connectivity	USB 2.0
Print Speed	20 ppm
Paper Sizes	A4, A5, A6, B5, Letter, Legal
Operating System Compatibility	Windows, Mac, Linux
Warm-up Time	Less than 15 seconds
Time to First Page	Less than 10 seconds
