Paper Jam Removal
3-19
When the jammed paper appears to be pinched by rollers, pull it along
the normal paper running direction.
4
After you have removed the jammed paper, put the process unit back
into the printer.
5
Close the printer’s front cover and top cover. The printer then
automatically warms up and resumes printing.
3.4.5 Jam at the MP Tray
When a paper jam occurs in the MP tray, clear it using the following
procedure.
1
Leaving any paper that may be jammed there, remove the rest of the
paper from the MP tray.
Figure 3-10
Do not try to forcefully pull out paper that has already been fed partially
in to the MP tray. Instead, proceed to the next step.
Figure 3-11
Note
Note
