Parallel Interface
B-3
[ ]: Signal names in the Auto mode and Nibble (high) mode (IEEE 1284). In the Auto mode and
Nibble (high) mode, these signals are bi-directional.
Pin In/out Description
1 In Strobe* [nStrobe]
2 In Data 0 [Data 1]
3 In Data 1 [Data 2]
4 In Data 2 [Data 3]
5 In Data 3 [Data 4]
6 In Data 4 [Data 5]
7 In Data 5 [Data 6]
8 In Data 6 [Data 7]
9 In Data 7 [Data 8]
10 Out Acknowledge* [nAck]
11 Out Busy [Busy]
12 Out Paper Empty [PError]
13 Out Online (Select) [Select]
14 In Ignored [nAutoFd]
15 - Not connected
16 - 0V DC
17 - Chassis GND
18 - +5V DC
19 - Ground return
20 - Ground return
21 - Ground return
22 - Ground return
23 - Ground return
24 - Ground return
25 - Ground return
26 - Ground return
27 - Ground return
28 - Ground return
29 - Ground return
30 - Ground return
31 In Reset [nInit]
32 Out Error*, returns error status if FRPO O2=2 [nFault]
33 - -
34 - Not connected
35 Out Power Ready
36 In Select In [nSelectIn]
Table B-1

Kyocera FS FS-1020D Specifications

General

Print Technology	Laser
Resolution	600 x 600 dpi
Memory	32 MB
Standard Input Capacity	250 sheets
Connectivity	USB 2.0
Print Speed	20 ppm
Paper Sizes	A4, A5, A6, B5, Letter, Legal
Operating System Compatibility	Windows, Mac, Linux
Warm-up Time	Less than 15 seconds
Time to First Page	Less than 10 seconds
