Kyocera KM-C2630D

Section 9 TROUBLESHOOTING
9-10
1
Open the right cover of the specified paper feeder.
2
Taking care not to tear the jammed paper, pull it from the
copier.
NOTES
• If the paper tears, remove all of the remaining pieces
from inside the copier.
• If the paper is jammed below the primary paper guide,
raise the primary paper guide and pull the paper out.
3
Push the drawer [cassette] back into the copier.
Misfeed in the multi-bypass tray
The screens shown below indicate that there is a misfeed in the
multi-bypass tray. Perform the following procedure to remove the
jammed paper.
Inch specifications
Metric specifications
1
Remove all of the paper remaining in the multi-bypass
tray.
2
Reload the paper into the multi-bypass tray.
1. Remove paper from bypass.
Paper misfeed.
JAM
1. Remove paper from bypass.
Paper misfeed.
JAM
