Kyocera TASKalfa 7353ci - Remove any Jammed Paper in the Top Cover, Right Cover 1 (Side Feeder (500-Sheet×3);Large Capacity Side Feeder (500, 1,500-Sheet×2))

10-95
Troubleshooting > Clearing Paper Jams
Remove any jammed paper in the Top Cover, Right
Cover 1 (Side Feeder (500-sheet×3)/Large Capacity
Side Feeder (500, 1,500-sheet×2))
See the explanation for Side Feeder (500-sheet×3) below.
1
Detach the side feeder.
2
Remove any jammed paper.
3
Open the side feeder top cover and the side feeder right cover
1.
CAUTION
• Do not reuse jammed papers.
• If the paper tears during removal, be sure to remove any loose scraps of paper from inside the machine.
Scraps of paper left in the machine could cause subsequent jamming.
