Kyocera TASKalfa 7353ci - Connecting USB Cable

To Next Page

To Previous Page

2-9

Installing and Setting up the Machine > Connecting Cables

Connecting USB Cable

Connect the cable to the machine.

1 Remove the covers from the machine in order from the top.

2 Connect the USB cable to the USB interface connector located on the left side of the body.

IMPORTANT

Make sure that the power to the machine is turned off.

Power Off (page 2-11)
