2-4

Installing and Setting up the Machine > Part Names (Connectors/Interior)

Part Names (Connectors/Interior)

1 USB Interface Connector

2 USB Port

3 Network Interface Connector

4 Option Interface Slot

5 Waste Toner Box Cover

6 Waste Toner Box

7 Toner Container Cover

8 Toner Container (Black)

9 Toner Container (Magenta)

10 Toner Container (Cyan)

11 Toner Container (Yellow)
