Kyocera TASKalfa 7353ci - Part Names (with Optional Equipments Attached)

2-5
Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)
Part Names (With Optional Equipments
Attached)
1 Tray 1 to 7 (tray 1 is the top tray)
2 Tray A
3 Tray B
4 Tray C
5 Folding Tray
Optional Equipment (page 11-2)
6 Side Feeder Top Tray
7 Cassette 5
8 Cassette 6
9 Cassette 7
10 Control Section of the Finisher
Manual Staple (page 5-74)
5
1
3
2
5
7
10
9
4
9
8
7
6
8
7
3
2
4
