Table 3-9-3 Various Functions in Function Selecting Mode (2/5)
Function Name
Key Operation and WGI-400A
Movement in Function Setting Mode
Functional Description
F-04
Numeric Value Registering
Calibration
(Calibration Zero
Registration
•
•
•
Displays calibration Zero value.
Changes the numeric value by key
operation.
Input the initial value of the transducer.
Press the SET key to determine the
indicated value.
•
•
A function that re-sets the
Zero value (a reference
value) when calibration.
For details, see “3-4-3
Numeric Value Registering
Calibration.”
F-05
Self-Check
“……” is displayed.
Press the SET key and all the indicator
LEDs light up to conduct self-check.
The self-check results are indicated as
described at the right.
• A function that self-checks
the internal memory and
displays the checked results.
● If faulty self-check results appear on
the indicator, contact KYOWA or our
representatives.
Good: Normal
E-01: RAM failure
E-02: Flash memory
failure
F-06
Analog Output
Initial value
‘0’: Zero
‘4000’: Full scale
• Select output
0: Voltage output
1: Current output
Select and press the SET key.
•
•
A function that sets and
defines Zero and full scale
with the indicated value.
Select the desired analog
output.
•
•
●
‘◦’ is displayed on the Status Indicator.
Set the indicated value to have the
output to ‘0 V or 4 mA’ and press the
SET key.
‘F’ is displayed on the Status Indicator.
Set the indicated value to have the
output to ‘10 V or 20 mA’ and press the
SET key.
Setting range: ±9999
• If the analog output exceeds
the full scale value by
approximately 5%, about 12
V is output. If it lowers to -
full scale, -12 V is output.
Current output is outputted
in the same manner,
approximately 12 mA and
0 mA.
.
