Table 3-8-3 Various Functions in Function Selecting Mode (3/5)
Function Name
Key Operation and WGI-400A
Movement in Function Setting Mode
Functional Description
F-07
Smoothing
Displays the following items 1) and 2). •
•
A function that stables the
indication by smoothing the
varying signals from the
transducer.
Number of moving average
times
The number of moving
average times to average
and display the measured
value.
Minimum scale
Minimum unit that varies
the indicated value.
To set the number of
display times relevant for
the WGI-300, select ‘4’ in
item 1) and set ’16.’
1) Number of moving
average times
2) Minimum scale
Initial value: ‘0.0’
Moving average: None
Minimum scale: 1
O:
1:
2:
3:
4:
5:
6:
7:
None
2 times
4 times
8 times
16 times
32 times
64 times
128 times
0:
1:
2:
3:
4:
5:
6:
1
2
5
10
20
50
100
•
•
Select and change values in items 1) and 2)
and press the SET key.
Note: When moving average times is set,
response of the analog output is
deteriorated.
F-08
Additional Value
• Set the desired additional value and
press the SET key.
• A function that adds the
desired numeric value to the
measured value for display.
Initial value: ‘0’ ● Setting range: ±9999 • Conduct digital Zero
function with the preset
additional value. Then, the
obtained value is displayed
on the indicator.
