Table 3-9-3 Various Functions in Function Selecting Mode (4/5)
Function Name
Key Operation and WGI-400A
Movement in Function Setting Mode
Functional Description
F-09
Auto Zero Compensation
Initial value: ‘0’
‘0.0’
‘0’
•
•
●
●
•
●
‘μ' is displayed on the Status Indicator.
Set Zero compensation range and press
the SET key.
‘t’ is displayed on the Status Indicator.
Set the judging time and press the SET
key.
Zero Compensation range: ±9999
Judging time: 0.0 to 9.9 (sec)
‘2’ is displayed on the Status Indicator
(ZERO).
Set Zero near Zero range and press the
SET key.
Zero near Zero range: 0 to 9
•
•
Zero tracking
When it passes the
judging time and
measured value is within
the Zero compensation
range, this function
activates digital Zero
function and
automatically Zeros the
indicated value.
Zero near Zero range
When the measured value
is within the Zero near
Zero range (Within
setting range), this
function automatically
Zeros the indicated value.
F-10
Hysteresis
Initial value: ‘0’
‘0’
•
•
●
‘1’ is displayed on the Status Indicator.
S
et hysteresis of the high limit
comparator and press the SET key.
‘2’ is displayed on the Status Indicator.
S
et hysteresis of the low limit
comparator and press the SET key.
S
etting range: 0 to 9999
• A function that sets the
hysteresis of the high and
low limit comparators
(Comparators 1 and 2).
F-12
Initialize
• Initialize 0: Not initialized
1: Initialized
Press the SET key. Then, the set value
returns to factory default setting.
•
A
function that returns the
set values to factory default.
● Calibration value and BV set value are
not initialized.
F-13
BV Select
Initial value: ‘0’
•
S
et BV set value. 0: 2 V
1: 4 V
S
elect either of the above volts and
p
ress the SET key.
•
A
function that selects and
c
hanges the bridge
e
xcitation voltage.
