KYOWA WGI-400A - SPECIFICATIONS; TECHNICAL SPECIFICATIONS

24
Table 3-8-3 Various Functions in Function Selecting Mode (5/5)
Function Name
Key Operation and WGI-400A
Movement in Function Setting Mode
Functional Description
F-14
Operation Pattern
Initial value: ‘0’
• Set value 0: Pattern 0
1: Pattern 1
2: Pattern 2
3: Pattern 3
After selecting the desired pattern, press
the SET key.
•
•
•
Select high/low limit
comparator values from 4
sets of patterns.
Factory default is ‘0.’
When no Pattern Select
Command from external
control input is connected,
this function is enabled.
F-20
TEDS Read Operation
Initial Value: ‘0.0.0.1’
Displays the items 1), 2), 3) and 4). •
•
A
llows or prohibits the
T
EDS reading operation.
I
n the factory default state,
t
he TEDS reading operation
i
s prohibited with the power
O
N.
1) External control input (setting not
available)
0: Allowed 1: Prohibited
2) RS command
0：Allowed 1: Prohibited
3) Key operation
0: Allowed 1: Prohibited
4) Power ON
0: Allowed 1: Prohibited
Select and change items 1), 2), 3), and 4)
and press the SET key.
F-21
TEDS Read Items
Initial Value: ‘0.0.0.’
Displays the items 1), 2) and 3). •
•
A
llows or prohibits the
T
EDS reading items.
I
n the factory default state,
a
ll the TEDS read items are
s
et to ‘0: Allow.’
1) Excitation voltage
0: Allowed 1: Prohibited
2) Rated output
0: Allowed 1: Prohibited
3) Rated capacity
0: Allowed 1: Prohibited
Select and change items 1), 2), and 3) and
press the SET key.
F-22
Digital Zero during TEDS
Operation
Initial Value: ‘0.’
0: Execute 1: Prohibited
Select and press the SET key.
•
•
E
xecute or prohibit digital
Z
eroing during Zero
o
peration.
I
n the factory default state,
i
t is set to ‘0: Execute.’
F-25
Level Test Signal
Initial value: ‘0’
‘1000’
•
•
●
Display additional function
Set value 0: Disabled
1: Enabled
After selecting either of the above,
press the SET key.
Setting the test value
After setting the test value, press the
SET key.
Setting range: ±9999
•
•
•
This function operates when
t
he level test command from
t
he control input is ON.
D
isabled:
Displays the level test
value irrespective of the
indicated value.
E
nabled:
The level test value is
added to the indicated
value and displayed.
