Three types of slides are used on KZ products:
1. Hydraulic on main floor.
2. Bedroom: (a) Schwintec and (b) Floor mounted.
SLIDE OUTS, MAIN FLOOR
The hydraulic system will provide energy to move slides in or out as
you desire. Each slide has it’s own valve with a black knob to turn,
3 to 4 turns will close and open it. Should you wish to move only
one slide, close the valve on the other slide.
With all valves open, the slide which is lightest in weight and offers
least resistance will move first. Generally, the left valve, door side
will be the first slide to move.
Basic components are cylinder, hoses, fittings, and oil inside
orange and black lines plus 12 volt DC motor to pump fluid through
the lines to make it all happen.
Cylinders are attached to rack and pinion track and to a bracket
welded to frame, plus fluid lines.
A 12 volt DC motor is attached to the pump, with fluid stored in
reservoir until it’s time to move slide.
The operation to move slide ( s ) in or out is contained in tablet as
part of the docking system. Follow directions as given by pad.
Always make sure that the slide path is clear of people and objects
before operating slide system. Always keep away from slide rails
when the room is being moved.
MANUAL OPERATION
The hydraulic slide out system can be operated with an electric drill
or screw gun. In the event of electrical failure, use this method of
extending or retracting slide. Follow these instructions.
1. Remove protective cover from top of motor.
2. Use a stand hex bit, insert into auxiliary drive device with screw
gun ratchet wrench.
3. Insert hex bit into coupler found under protective cover.
4. Run screw gun forward or clockwise and in reverse or counter
clockwise for hydraulic operation.
