2. Push or pull slide room in as desired. Larger rooms may
require several persons to push room. Keep both sides even.
3. When room is completely in, plug both motors back into the
circuit board to apply brake to travel.
4. Room must be travel locked during travel time.
BEDROOM SLIDE OUT, FLOOR MOUNTED
This assembly is placed and attached to the floor of the front
bedroom slide. Two rollers are also attached to side wall at opening
point to give ease in slide out movement, in or out. This includes all
hardware, motor gears, shafts, track and framework. Switch to
operate bedroom slide is in the bed room area.
MANUAL OVERRIDE, BEDROOM SLIDE
Access to move slide when no power is available is under the bed.
1. Remove any and all cargo from under the bed.
2. Pull up plywood panel covering mechanism.
3. Find shaft on front side of gear box. Use 3/4” socket and
ratchet to turn shaft in direction you wish to move slide, in or
out.
NOTE: Bedroom slide is fully 12 volt DC powered and NOT
hydraulic.
Stand clear of the room’s interior path and verify that the room’s exterior
path is clear before extending or retracting the room.
WARNING
!
When opening slide room, DO NOT over-extend. Fascia board can be dis-
torted, loosened or bent from correct position.
CAUTION
!
Because operating the slide-out draws up to 15 amp current from the bat-
tery, some source of supplemental charging should be operating while ex-
tending or retracting the slide-out.
CAUTION
!
