48
CHAPTER 4
SYSTEMS
WATER AND DRAINAGE PLUMBING
Your KZ recreational vehicle has a complete water system, to carry
fresh water, as well as holding tanks for used water. Each group
has its own explanation along with its own operation.
FRESH WATER SYSTEM
Tanks
All coaches produced by KZRV have a fresh water supply tank
installed. In most models, it’s located under the floor, in between
frame main rails. It is protected with a cover on the bottom, steel
rails on each side. Tank also has an over flow line, smaller than fill
line. Over filling tank may cause tank to become pressurized,
breaking, leaking, and bending carrier frame, which is NOT a
manufacturing defect or covered by warranty.
These tanks are NOT designed to hold pressure. See Caution.
LIQUID CONTROL CENTER—VENOM
All functions of water movement is controlled by this center, located
in left front corner of your coach. There are numerous features in the
operation, filling, distributing, plus switch for water pump and T.V.
antenna hook-up.
Components listed are:
P—Pump switch to start and stop pump, 12 volt DC.
S—Satellite and cable hook-up.
F—Faucet for exterior use as needed with quick connect hose and
sprayer.
C—City water fill attaches to your supply hose plus use as a siphon
hose application, described later.
B—Black tank flush to be used AFTER black holding tank has been
drained to rinse out any left over items.
There is a second ‘Black Flush” connection for rear sewer tank
DO NOT leave tank unattended while filling, as an over filled tank will build
pressure, causing tank to crack, rupture, and leak or even damaging sup-
ports holding it in place.
!CA CAUTION
!
