42
For landing jacks add two more steps:
1. Locate landing gear valve on jack or on valve body.
2. Turn manual override (knurled knob on the thumbscrew style or
using an Allen wrench on the Set Screw style) clockwise or to
the right looking into the end of the valve approximately 1 1/2
turns. Be careful not to tighten override as over tightening will
damage the valve needle.
More information can be found in the Lippert manual.
BEDROOM SLIDE OUT, SCHWINTEC ( In wall System )
System is used for ward robe and/or bedroom in front end of VENOM.
System is composed of 4 tracks placed on the outer sidewall of the
slide, 2 at the bottom and 2 at the top near roof line. On each side an
extrusion is attached to the sidewall with a motor in at the top. A gear
is mounted to the motor which will run on the upper track to move
slide in or out. Wire harness is along side of extrusion. Motor is
accessible only on the inside.
On the bottom is a roller moving on the track, not in any groves, to
stabilize slide.
Power is supplied by 12 volt DC convertor and/or an auxiliary battery
through a module board, located under slide or near the slide in a
cabinet.
Switch and module are both placed inside of coach with a two wire
harnesses, one going to each motor.
MANUAL OVERRIDE, SCHWINTEC
A. ELECTRIC MANUAL OVERRIDE
1. Locate the circuit board.
2. Press the mode button six times quickly, press a 7th time
and hold for approximately 5 seconds. The red and green
LED lights will begin to flash, confirming the override mode.
3. Release the mode button.
4. Back inside coach use the normal control switch to retract the
room.
B. MANUALLY PUSH ROOM IN OR OUT
1. Unplug both motors from circuit board. This releases the
motor brake.
