EN
9 SPECIFICATIONS
Reference 8XT
Frequency response
Usable bandwidth (-10dB) 65 - 20k Hz ([8XT_FR] preset)
SPL max levels
1
117 dB continuous 123 dB peak (1 x 8XT, [8XT_FI] preset)
Nominal directivity (-6dB) 100° (±15°) axi-symmetric
Transducers
LF
1 x 8’’ weather-resistant transducer mounted in a bass-reflex tuned enclosure
HF
1 x 1.5’’ diaphragm compression driver coaxially-loaded by the 8’’ LF transducer
Filters Passive 3
rd
order crossover network
Nominal impedance 8 Ω
Connectors 2 x 4-pin NEUTRIK
®
NL4FC Speakon
®
(wired in parallel)
Dimensions (H x W x D) 422 x 250 x 271 mm
Ö
16.6 x 9.8 x 10.7 in
Weight 11 kg
Ö
24.3 lbs
Flying
Ö
One 35 mm/1.38in pole socket and one 10mm/0.39in insert for wall or
ceiling-mounting using the L-ACOUSTICS
®
ETR8-2 adjustable mounting
accessory (available in option).
Ö
Four predrilled 6mm/0.24in inserts for wall or ceiling-mounting using
the OMNIMOUNT
®
30.0 SERIES mounting accessories.
Ö
One 8 mm/0.31in safety eye-bolt insert.
Stacking
Ö
Two fixed angle settings of 30° and 40° with regard to the vertical.
Ö
One 35 mm/1.38in socket for pole mounting.
External structure
Material 15 and 18 mm Baltic birch plywood.
Finish Maroon-gray, RAL 8017.
Front Cataphoresis-coated steel grill, acoustically neutral Airnet cloth.
Rigging Black epoxy-coated steel.
Grip handle Integrated into the cabinet.
1
Max SPL at 1m under freefield measurement conditions using pink noise with specified preset and corresponding EQ settings.
