5.2 ETR12 and ETR15 mounting accessories
The L-ACOUSTICS
®
ETR12 (resp. ETR15) U-bracket (Figure 4) is adapted for attaching an L-ACOUSTICS
®
12XT
or 112P (resp. 115XT HiQ) enclosure. It can be either fastened to a wall or suspended from a structure or ceiling
(typically for under-balcony applications).
It is possible to secure the ETR12 (resp. ETR15) to a structure using three 10mm/0.39in screws (not provided).
It is the sole responsibility of the user to verify that the ETR12 (resp. ETR15) is correctly secured to
the structure.
L-ACOUSTICS recommends securing to a concrete ceiling using expansion anchors designed to
support at least 5 times the total load of the system (the weight of the product is indicated on the
identification label of each product).
The ETR12 (resp. ETR15) can support one 12XT or 112P (resp. 115XT HiQ) at the maximum.
Figure 4: The ETR12 mounting accessory
Note: The ETR12 and ETR15 share the same design, the ETR15 being of a larger size than the ETR12.
