L-Acoustics 8XT - XTLIFTBAR Rigging Accessory

XTP_RM_ML_1
www.l-acoustics.com
11 en
EN
5.4 XTLIFTBAR rigging accessory
The L-ACOUSTICS
®
XTLIFTBAR (Figure 6) is to be used for flying the L-ACOUSTICS
®
112XT, 112P, or 115XT
HiQ enclosures.
It is provided with one shackle that can support up to 250kg/551 lb with an Ultimate Strength Safety Factor of 5:1. This
shackle allows for flying the 12XT, 112P, or 115XT HiQ enclosures using one rigging point.
The XTLIFTBAR can support one 12XT, 112P, or 115XT HiQ at the maximum.
Figure 6: The XTLIFTBAR rigging accessory
Shackle
Stud
Locking pins
!
WARNING
