L-Acoustics 8XT - Specifications

XT COAXIAL RANGE - P SELF-POWERED COAXIAL RANGE
Rigging Procedures
VERSION 1
XTP_RM_ML_1
www.l-acoustics.com
22 en
8 SPECIFICATIONS
Reference ETR8-2
Dimensions (W x H x D) 485 x 225 x 50 mm Ö 19.1 x 8.9 x 2 in
Weight 1.9 kg Ö 4.2 lb
Setup safety limit Maximum of one 8XT or 108P enclosure per ETR8-2
Material black epoxy-coated steel
Reference ETR12
Dimensions (W x H x D) 630 x 324 x 54 mm Ö 24.8 x 12.8 x 2.1 in
Weight 5.25 kg Ö 11.6 lb
Setup safety limit Maximum of one 12XT or 112P enclosure per ETR12
Material black epoxy-coated steel
