5.3 ETR15P mounting accessory
The L-ACOUSTICS
®
ETR15P U-bracket (Figure 5) is adapted for attaching an L-ACOUSTICS
®
SB15P enclosure. It
can be either fastened to a wall or suspended from a structure or ceiling (typically for under-balcony applications).
It is possible to secure the ETR15P to a structure using three 10mm/0.39in screws (not provided).
It is the sole responsibility of the user to verify that the ETR15P is correctly secured to the structure.
L-ACOUSTICS recommends securing to a concrete ceiling using expansion anchors designed to
support at least 5 times the total load of the system (the weight of the product is indicated on the
identification label of each product).
The ETR15P can support one SB15P at the maximum.
Figure 5: The ETR15P mounting accessory
