La Pavoni BAR 2 - ECO Max Electric Heating; Rated Electric Heating; Technical Diagram and Specifications

30
31
4 - TECHNICAL DIAGRAM AND SPECIFICATIONS
1. CUP-WARMER LUMINOUS SWITCH
2. LIVE MACHINE WARNING LIGHT
3. 4-POSITION GENERAL SELECTOR
4. FRONT PANEL
5. GAS DETECTION BUTTON
6. PIEZOELECTRIC IGNITER
7. AUTOMATIC BAR CAPPUCCINO
8. DATA PLATE
9. MANUAL BOILER WATER FILLING BUTTON
10. TELESCOPIC HANDLE
11. STEAM NOZZLE
12. PUMP AND BOILER PRESSURE CONTROL MANOMETER
13. TELESCOPIC HOT WATER SUPPLY NOZZLE
14. STEAM TAP KNOB
15. HOT WATER SUPPLY SWITCH
16. AUTOMATIC CAPPUCCINO TAP KNOB
17. UNIT CONTROL
18. CONTROL INSTRUMENT BOARD
19. CUP HOLDER
20. STEAM TAP KNOB
21. BREWING UNIT
22. FILTER-HOLDER
23. WATER LEVEL INDICATOR
24. DRAIN TRAY
25. DRAIN TRAY GRID
28. FROTHER TUBE
29. FROTH REGULATION HANDWEEL
ELECTRIC CIRCUIT ACTIVATION, HEATING ELEMENT EXCEPTED
HEATING ELEMENT NORMAL POWER CONNECTION
HEATING ELEMENT MAXIMUM POWER CONNECTION
Rated electric heating
BAR V 415 3N~/ V 240~
V 400 3N~/ V 230~
HOTEL V 120~
ECO max electric heating
BAR V 415 3N~/ V 240~
V 400 3N~/ V 230~
HOTEL V 120~
Pump Motor
Gas heating
W
W
W
W
W
W
W
KcaI/h
2 gr.
4760
4370
3000
3170
2900
1990
100
1700
3 gr.
5950
5465
--
3950
3640
--
165
2500
4 gr.
7140
6555
--
4750
4360
--
165
3400
2 unit
BAR BAR L
780 780
14 13
63 75
3 unit
BAR BAR L
990 990
22,5 21
78 90
4 unit
BAR BAR L
1200 1200
30 28
93 105
2 unit
HOTEL
605
10
53
MODEL
Width in mm
Boiler
Capacity in l
Weight in kg
3
13
12
11
20
21
22
23
11
24
25
19 18 17 16 15 14
1 2 3 4 5 6 7 8 9 10
L
555 mm
530 mm
General selector
28
29
7
