The FT Series Floor Standing, Combination Boiler
Page 91
FTCF199
Tank and Water Pipe Parts
No. Description Part Number
29 DHW Water Tank Ass’y FT3046
30 Internal Circulation Pipe 2 Ass’y FT3047
30-1 Internal Circulation Pipe 2
P-4 1” Packing FT1691
31 Boiler Pump Ass’Y FT3049
31-1 Boiler Pump
P-4 1” Packing FT1691
B-1 M4 x 10MM Pan Head Screw
(ne thread)
32 Pump Bottom Pipe Ass’y FT3051
32-1 Pump Bottom Pipe
P-4 1” Packing FT1691
33 CH Return Connection Ass’y FT3053
33-1 CH Return Connection
33-2 Ball Valve FT1708
33-3 Short brass tting FT3055
C-1 Piping Clip1 FT1107
O-24 O-Ring P24 FT3056
P-4 1” Packing FT1691
34 CH Return Pipe Ass’y FT3057
34-1 CH Return Pipe
C-1 Piping Clip1 FT1107
O-24 O-Ring P24 FT3056
P-4 1” Packing FT1691
35 CH Return Connection FT3059
36 CH Return Sensor FT1635
37 3way Connection Ass’y FT3060
37-1 3way Connection
P-1 3/8” Packing FT3062
P-4 1” Packing FT1691
O-24 O-Ring P24 FT3056
C-1 Piping Clip1 FT1107
C-2 Piping Clip2 FT1108
38 CH Supply Pipe Ass’y FT3063
38-1 CH Supply Pipe
P-4 1” Packing FT1691
O-24 O-Ring P24 FT3056
C-2 Piping Clip2 FT1108
39 CH Supply Connection FT3065
40 Adapter Pipe Ass’y FT3066
40-1 Adapter Pipe
P-4 1” Packing FT1691
41 Adapter Connection FT3068
42 Internal Circulation Pipe 1 Ass’y FT3069
42-1 Internal Circulation Pipe 1
P-4 1” Packing FT1691
43 DHW Outlet Pipe Ass’y FT3071
No. Description Part Number
43-1 DHW Outlet Pipe
O-18 O-Ring P18 FT1687
C-3 Flow Sensor Clip FT1208
P-3 3/4” Packing FT1646
44 DHW Outlet Connection FT3073
45 DHW Outlet Sensor FT1638
46 DHW Inlet Pipe2 Ass’y FT3074
46-1 DHW Inlet Pipe2
P-3 3/4” Packing FT1646
O-18 O-Ring P18 FT1687
O-20 O-Ring P20 FT1513
C-1 Piping Clip1 FT1107
C-3 Flow Sensor Clip FT1208
47 Flow Sensor Ass’y FT3076
47-1 Flow Sensor
C-3 Flow Sensor Clip FT1208
O-16 O-Ring P16 FT1643
O-18 O-Ring P18 FT1687
48 Recirculation Connection FT3077
48-1 Check Valve FT3078
49 Elbow Connection Ass’y FT3079
49-1 Elbow Connection
O-16 O-Ring P16 FT1643
O-18 O-Ring P18 FT1687
C-3 Flow Sensor Clip FT1208
50 DHW Inlet Pipe Ass’y FT3081
50-1 DHW Inlet Pipe
O-16 O-Ring P16 FT1643
O-18 O-Ring P18 FT1687
C-3 Flow Sensor Clip FT1208
51 Inlet Pipe Adapter Ass’y FT3083
51-1 Inlet Pipe Adapter
C-5 Adapter Clip FT3085
O-16 O-Ring P16 FT1643
O-20 O-Ring P20 FT1513
C-3 Flow Sensor Clip FT1208
52 DHW Filter Body Ass’y FT3086
52-1 DHW Filter Body
52-2 Block Cap FT1121
52-3 DHW Filter Mesh FT1120
52-4 Flow restrictor FT1822
O-16 O-Ring P16 FT1643
O-20 O-Ring P20 FT1513
C-4 R Clip FT1524
C-5 Adapter Clip FT3085
53 DHW Inlet Connection FT3088
B-10 M5 x 10MM Hex Head Screw
(ne thread)
