The FT Series Floor Standing, Combination Boiler
Page 93
FTCF199
Heat Exchanger and Tank Parts
No. Description Part Number
54 Exhaust Duct Ass’y FT3090
54-1 Exhaust Duct
54-2 Exhaust Overheat Sensor FT1307
54-3 Exhaust Duct Packing (Lower) FT2036
P-1 3/8” Packing FT3062
B-11 M4 x 9MM Hex Head Screw (coarse thread)
55 Heat Exchanger Ass’y FT3093
56 Burner Ass’y FT3094
56-1 Burner Upper Case FT1760
B-10 M5 x 10MM Hex Head Screw (ne thread) FT3089
56-2 Burner Packing FT1824
56-3 Burner FT1838
56-4 Ignition Rod Ass’y FT3127
56-4a Ignition Rod FT2040
56-4b Ignition Rod Gasket 1 FT1316
56-4c Ignition Rod Gasket 2 FT2017
B-15 M4 x 14MM Socket Head Cap Screw (ne thread)
56-7 Overheat Sensor FT1310
B-14 M3 x 6MM Socket Head Cap Screw (ne thread)
56-8 Burner Downside Case FT2041
56-9 Refractory FT3095
B-10 M5 x 10MM Hex Head Screw (ne thread)
57 Overheat Temperature Sensor FT1324
58 Low Water Cut o󰀨 Sensor FT1325
59 Flame Detecting Sensor Ass’y FT2085
59-1 Flame Detecting Sensor Bracket FT1669
59-2 Flame Detecting Sensor FT1327
59-3 Flame Detecting Sensor Cover FT1069
B-13 M4 x 14MM Pan Head Screw (coarse thread)
60 Condensate Trap Sub Ass’y FT3098
60-1 Condensate Trap Ass’y
60-2 Condensate Trap Bracket 1 FT3100
60-3 Condensate Trap Cap FT3101
O-22 O-Ring P22 FT1644
P-2 1/2” Packing FT1875
B-7 M4 x 14MM Pan Head Screw (coarse thread)
B-9 M5 x 12MM Washer Head Screw (ne thread)
B-12 M5 x 16MM Pan Head Screw (ne thread)
