CHAPTER 0SYSTEM DESCRIPTION
This chapter covers the following Labcyte Echo liquid handler features and
components:
 System overview
 Front panel
 Back panel
 Component description
 Process door
 Source plate gripper stage
 Source plate insert
 Destination plate gripper stage
 Status indicator lights
 LCD screen
 Emergency Off switch
 Anti-static bars
 AC power and fuse compartment
 Coupling fluid bottle
 Fluid chiller
 Surge tank
 Fluidics panel
 Specifications
 Physical
 Mechanical
 Environmental
 Electrical
 Communications
 Fluid transfer
 Client PC
 Supported labware
 Coupling fluid
