3-12 Echo Liquid Handler User Manual
3.2.8 Anti-static bars
The upper and lower anti-static bars (also called ionizer bars) remove any
electrostatic charge from the source and destination microplates.
Electrostatic charge can affect the placement of the transferred drop during
liquid transfer.
Figure 3.12 Anti-static bars
Barcode scanner
The barcode scanner is optional. You can purchase one or more barcode
scanners to add to your Echo liquid handler that will read and report
barcoded microplates.
Figure 3.13 Barcode scanner locations
Lower anti-static bars
Upper anti-static bar
Right Barcode Scanner
Left Barcode Scanner
Front Barcode Scanner
(not shown)
