29
MAINTENANCE
1.4.6 HYDRAULIC CYLINDERS INSPECTION
PROCEDURES
To maintain proper working order and prolonged
cylinder performance, it is essential to inspect
them at least once a week as recommended.
Verify that all the connections of the flexible
hoses and pipes are tight, and that there are no
external leaks.
Check that all the cylinder head cap screws are
firmly tightened and that there are no leaks.
All leaks must be corrected immediately by
replacing damaged or worn seals with new
ones. Lubricate and inspect all the cylinder
mounting points (pins, retaining bolts, etc.).
1.4.7 HYDRAULIC RESERVOIR INSPECTION
PROCEDURE
Verify that the oil in the reservoir is clean and
always at the proper level.
HYDRAULIC RESERVOIR
MAINTENANCE PROCEDURE
• For increased longevity, clean the
strainer inside the reservoir after
the first 50 hours of service and
annually thereafter (Figure #1.16).
• Verify the cleanliness of the filler
cap (NOT BLOCKED, Figure #1.16).
• Verify the cleanliness, the color and
the level of the hydraulic oil. (level
at 3/4 of the oil level gauge, with all
cylinders retracted).
MAXIMUM TEMPERATURE FOR
HYDRAULIC FLUID IS 180°F, +/-
10°F
The maximum temperature for the system should
not exceed 180°F +/- 10°F. Refer to the hydraulic
parts section (Chapter 8) for parts numbers.
CAUTION
