33
MAINTENANCE
CAUTION
1.4.11 TAILGATE HYDRAULIC SYSTEM
MAINTENANCE
The OPTIMIZER
TM
units are equipped with a
special hydraulic system that controls the
locking mechanism of the tailgate.
If the continuous re-locking system is not working
properly: tailgate unlocks by itself or if the
tailgate is dropping from the fully open position
by itself refer to section 6.4 for troubleshooting.
1.4.12 CYCLE TIME TABLE FOR ALL
HYDRAULIC FUNCTIONS
FUNCTIONS CYCLE TIME
Packer blade: 22 sec
Tailgate: 45 sec
Sliding roof: 15 sec
Lifting arm: 15 sec
Forks: 5 sec
Packer ejection mode:
Extend 24 sec
Retract 10 sec
ENGINE RPM : 1500
1.4.12 BODY HOISTING SYSTEM
MAINTENANCE
The OPTIMIZER
TM
is equipped with a hoisting
system used to raised the body. This system
is fed by its own hydraulic pump (see Figure
#1.21.
Since this pump is energized by electrical
cables, it is protected by a cover.
The pump of the body hoisting system must
be adjusted to 2000 PSI.
To do so, proceed with the following steps:
• Install a 3000PSI pressure gauge on
the quick coupling found on the
pump (see Figure #1.21).
• By using the pump manual lever
(see Figure #1.22), raise the body
until the mechanism reaches the
end of its stroke.
• Check the pressure while the body
is held fully raised.
BODY HOISTING SYSTEM PUMP
ADJUSTMENT
ALWAYS BE EXTREMELY
CAREFUL WHEN WORKING
NEAR THE PUMP ELECTRICAL
TERMINALS. FAILURE TO DO SO
MAY RESULT IN SERIOUS
INJURIES, ELECTROCUTION OR
EVEN DEATH.
