only after its removal from the vehi-
cle, for this loosen screws 6, insert a
screwdriver into chase 4, press to the
centre of latch 5 and carefully remove
headlight glass 2 with the screwdriv-
er. Bulb 3 in housing 1 is held with
spring contacts. To replace light bulb
1 (Fig. 61b) in the licence plate light,
«liftback» vehicle, you should remove
the light from the vehicle.
In the socket the light is held with
spring latch and striker plate.
Insert a flat screwdriver into chase
on the light left side of the roof light,
carefully move it to the right and
throw out the striker plate of engage-
ment. Turning socket 3 counterclock-
wise, remove it and the bulb from the
light housing 1 and pull bulb 2.
After replacing the bulb the
assembly and installation of the
licence plate light should be carried
out in reverse order.
Interior ceiling light
To replace the bulbs in the interior
ceiling light you should remove head-
7* 99
light lens 1 (Fig. 62) from the light
mounting frame. The ceiling light is
held with metal retaining spring and
hooks in the back of the mounting
frame bracket. To remove ceiling
light you should insert a flat screw-
driver into the chase on the right side
of the light (from the side of the front
Fig. 62. Interior ceiling light
Fig. 63. Interior illumination unit
Fig. 61b. Licence plate light in
«liftback» vehicle
