ALIGNING TABLE PARALLEL TO BLADE
Fig. F
Fig. G Fig. H
STEP 1: Loosen 4 bolts as shown.
STEP 2: Adjust table parallel to T-Slot (miter
slot), by pivoting table. Use a ruler to measure
from blade to T-Slot at the front and rear of
blade.
STEP 3: Tighten 4 bolts as shown.
T-Slot (Miter Slot)
