laguna Fusion 3 - Page 66

Fusion 3 Table Saw \ Replacement Parts Table \
58
© 2020 Laguna Tools
Parts List
Key
Part No.
Description
Specifications
Qty
1
925199-000
Fence Assembly
L\H (800mm)
1
.2
310587-909
Adaptor
800mm
1
.3
000002-308
Hex Screw
M6-1.0x45
1
.4
171993-904
Bracket
1
.5
250602-621
Frictional Plate
1
.7
251456-620
Pointer
(L\H)
1
.8
001101-205
Pan Head Tapping Screw
M3-1.06x6
2
.9
000304-210
Pan Head Screw
M6-1.0x6
2
.10
174903-308
Fence Body
1
.11
008005-100
Hex Nut
M6-1.0 (10Bx5H)
1
.12
250587-615
Frictional Wheel
1
.15
250472-621
Plastic Set Screw
M12-1.75
2
.16
000004-306
Hex Screw
M10-1.5x50
1
.17
230282-615
Ball
1
.18
922141-000
Compress Cam Assembly
1
.19
250471-621
Frictional Plate
2
.20
002103-103
Flat Head Screw
M6-1.0x8
2
.21
171372-904
Bracket for Frictional Plate
1
.22
008308-100
Lock Nut
M10-1P (17Bx12H)
1
.23
008304-100
Lock Nut
M6-1.0 (10Bx6H)
1
.24
001903-105
SET Lock Screw
M8-1.25x8
2
.25
250672-615
Spacer
4
.26
380883-901
Handle Shaft
1
.32
270007-901
Spring Plate
2
.33
000302-101
Pan Head Screw
M4-0.7x6
4
.35
174713-000
Fix Plate
1
.36
251433-615
Wing Screw
3
.37
250624-615
End Cap
1
.38
175051-905
Pointer Bracket
1
2
924883-000
Blade Guard Assembly
1
