laguna Fusion 3 - Page 67

Fusion 3 Table Saw \ Replacement Parts Table \
© 2020 Laguna Tools
59
Key
Part No.
Description
Specifications
Qty
.1
251246-000
Right Cover
1
.2
290073-905
Shoulder Shaft
4
.3
251247-000
Left Cover
1
.4
043317-000
O-Ring
P006
4
.5
924884-000
Blade Guard support Assembly
1
.5.1
924885-000
Support (L)
1
.5.2
924886-000
Support (R)
1
.5.3
001201-002
Tapping Screw
M4-1.41x20
6
.5.4
008005-200
Hex Nut
M6-1.0P (10Bx5H)
1
.5.5
360960-901
Pin
2
.6
008302-100
Lock Nut
M5-0.8 (8Bx6H)
1
.7
230336-615
Bolt
1
.9
171378-904
Anti-Kick Finger -Left
1
.10
280162-901
Spring
1
.11
251311-615
Block
1
.12
360864-000
Pin
1
.13
360865-901
Spreader Shaft
1
.14
280160-901
Spring
1
.15
010204-000
Retaining Ring
ETW-7
1
.16
280163-901
Spring
1
.17
171379-904
Anti-Kick Finger -Right
1
.18
000303-110
Pan Head Screw
M5-0.8x30
1
.19
174397-904
Spreader
1
.20
006001-012
Flat Washer
5.3x12x1.0
2
3
924562-000
Miter Gauge Assy
1
.1
230191-000
Handle
1
.2
006002-056
Flat Washer
8.5x23x2
1
.3
310500-911
Apron
1
.4
003001-102
Hex Screw
1/4"-20x1"
2
.5
090342-008
Miter Gauge Body
1
.6
230408-000
Lock Handle
2
.7
360355-901
Pin
1
.8
000204-114
SET Screw
M8-1.25x6
2
.9
381390-904
Slot Bar
1
