laguna Fusion 3 - Page 71

Fusion 3 Table Saw \ Replacement Parts Table \
© 2020 Laguna Tools
63
Key
Part No.
Description
Specifications
Qty
94
360709-901
Worm Shaft
1
95
001902-109
SET Lock Screw
M6-1.0x6
2
96
012002-006
Key
4x4x16
1
97
130126-903
Lock Ring
1
98
006006-120
Flat Washer
20x10.2±0.1x2±0.1
1
99
006004-167
Flat Washer
13x28x0.8
1
100
000104-108
Cap Screw
M8-1.25x25
3
101
361428-901
Shaft
1
102
381463-901
Bushing
1
103
000304-107
Pan Head Screw
M6-1.0x16
4
104
251239-615
Motor Cover
1
105
051135-000
Trunnion Support
2
106
000003-105
Hex Screw
M8-1.25x25
6
109
000003-115
Hex Screw
M8-1.25x55
1
110
020003-000
Strain Relief
SB7R-3
1
111
006001-001
Flat Washer
4.3x10x1.0
2
112
000302-102
Pan Head Screw
M4-0.7x8
2
113
004001-101
Knob
5/16"-18x3/4"
2
114
000003-316
Hex Screw
M8-1.25x60
2
115
250399-615
Wheel
2
116
006001-022
Flat Washer
6.3x13x1.0
4
117
230041-000
Leveling foot
2
118
170541-904
Slide Shelf
2
119
049201-101
Hex Screw w/Flat Washer
M8-1.25x16 (13Bx6.5H)
2
120
251251-615
Storage Box
1
121
001603-102
Round Head Screw w/Washer
M6-1.0x10/6x13.2x1.0
6
122
170965-904
Fix Plate
1
123
250407-615
Worm Shaft Bracket
1
124
938085-000
Magnetic Switch Assy
3HP
1
127A
924914-000
36" Rail. Right Table. Rear
Table Assembly
1
1
924915-000
36" Rail Assembly
36"
1
.1
924923-000
Rear Rail
36"
1
